CNLINKO Manufacturer IP68 Waterproof 2 Pin Metal Male Female M16 Power Waterproof Plug Cable Socket Connector

Name: CNLINKO Manufacturer IP68 Waterproof 2 Pin Metal Male Female M16 Power Waterproof Plug Cable Socket Connector
Brand: Cnlinko
Price: 6.37 USD

Wholesale CNLINKO Manufacturer IP68 Waterproof 2 Pin Metal Male Female M16 Power Waterproof Plug Cable Socket Connector from china suppliers

Place of Origin : Guangdong, China

Brand Name : Cnlinko

Model Number : LP-16-C02PE-03-001

Certification : CE,ROHS,CCC,ISO9001

MOQ : 2

Price : $6.37-7.43

Type : Power

Application : Industrial

Gender : male and female, Female +male

Protection level : IP65/IP67

Pin : power connector 2 pin

Current rating(A) : 10A

Shell & Insulated Parts : High Performance Engineer Plastic

Hardware Matel : Zinc Alloy (pearl hard chromium)

Connecting mode : plug/unplug

Operating voltage : 500V

Cable Spec : 18-16AWG

Contact Now

Product Description

Specifications

IP67 waterproof 2 pin male female power connector manufacturer

Specifications
Connecting mode	Latching Lock connect
Protection level	IP65/IP67
Cable specification	1.0~1.5mm² /18AWG
Diameter range	Φ3mm ~Φ8.5mm
Contact diameter×Qty	Φ1.5×2
Current rating(A)	10A
Temperature rise	10A contact temperature below 30℃ 12A contact temperature below 40℃ 15A contact temperature below 50℃
Operating voltage(AC.V.rms)	500V
Withstanding voltage(AC.V)1min	2500V
Contact resistance	<2.5mΩ
Insulation resistance	>500MΩ
Durability	≥500 mating&unmating cycles
Temperature rating	-40°C~80°C
Method of connecting cable	Soldering
Prevent the combustion level	UL94-V0
Material
shell & Insulated parts	High performance engineering plastics
Hardware metal	Zinc alloy(pearl hard chromium)
Contact pin	Copper alloy(gold-plated 4U)
Spring	Stainless steel
Sealing	Silica gel
Main characteristics
Sealed against dust and fluid (IP65/IP67)
Vibration resistance,impact resistance,stretching resistance
socket with cover
Application industries
Stage equipment - The smart grid
Medical equipment - Server
Solar energy equipment - Ship equipment
Electric power equipment - Vehicle equipment
Communications equipment - Heavy machinery

Certifications
